*Colors you see here digitally may vary from the actual results. For a more accurate color representation, view a color swatch in the space in which your project resides.
15-30 min @ 380 °F (193 °C)
10-20 min @ 400 °F (204 °C)
7-14 min @ 420 °F (216 °C)
*Temperature and time to be adjusted to accomplish proper curing of coating. This can be achieved using infrared, convection, or combination ovens.
- Available in a wide range of colors and glosses
- Excellent exterior durability
- Good chemical resistance
FLAT BLACK
Product Details
Product Overview
Product Name
FLAT BLACK
Product SKU
PCAT99115
Chemistry
Polyester Acrylic Ultra Durable
Appearance
Smooth
Color
Flat Black
Description
PPG's Enviracryl™ and Envirocron® powder coatings are aesthetically pleasing, produce a durable uniform matte finish and can be custom formulated in a variety of surface textures.
PPG's "World Class" Ultradurable Polyester Acrylic Powder Coatings provide excellent durability and performance properties. This extensive line of Ultradurable Polyester Acrylic Powders is manufactured to meet the increasing quality requirements of the automotive, industrial and commercial markets. These sophisticated ultradurable polyester acrylics are the solution to your smoothness, durability and physical property requirements. An unsurpassed application development program enables consistently friendly use on a variety of substrates.
Technical Specifications
Product Properties
Wet: 100% (5B Pass)
Boiling Water: 100% (5B Pass)
Blister rating - 8 minimum
Scribe rating - 7 minimum
Blister rating - 8 minimum
Application Details
Chemistry
Polyester Acrylic Ultra Durable
Application Description
- Electrostatic Spray
- Coating can be applied with automatic and manual devices.
- Substrate should be correctly cleaned before use.
- Do not mix this product with other powder coatings.
- Color and finish influenced by film thickness: a good control of the film thickness will help the consistency of the aspect.
Surface Preparation
- Surface preparation should be chosen according to the type of substrate and required performance.
- The coater should test the suitability of the surface preparation before the application using appropriate test methods.
Curing Window
- See Cure Curve PCA-002
- 15-30 min @ 380 °F (193 °C)
- 10-20 min @ 400 °F (204 °C)
- 7-14 min @ 420 °F (216 °C)
- *Temperature and time to be adjusted to accomplish proper curing of coating. This can be achieved using infrared, convection, or combination ovens.
Test Conditions
Storage & Handling
Shelf Life
6 months at 77 °F maximum
Storage Conditions
Materials need to be stored in sealed plastic bags under dry and cool conditions. Do not expose to sunlight.
Environmental Aspects
For comprehensive Health, Safety, and Environmental advice, please refer to the relevant Safety Data Sheets, and information printed on the product label.
Warnings
⚠ WARNING: Cancer - www.P65Warnings.ca.gov.
Envirocron® Powder Coatings
PPG's ENVIROCRON® powder coatings are a comprehensive range of powder coatings engineered to deliver innovative solutions for every application. Envirocron products are specifically formulated without volatile organic compounds (VOCs) and offer excellent durability, making them the first choice of many OEMs, manufacturers and applicators around the world.
